Installing and Using DSF

July 10th, 2007 - Fernando Roberto

You are probably already tired of reading that OSR has hardware kits for driver development training for USB and PCI. It’s really frustrating to want to learn how to develop drivers that control board without even having one around. But I am poor and I have no money to buy these imported toys. Actually, I also got some pain when I had to go to the post office to get two kits I had bought and paid a tax of U$ 183.59, not counting the kit’s cost. Well, this is a point.

Assuming you are already an experienced programmer and knows how to make drivers for USB devices with one tied eye behind your back, imagine that you have to write a driver for a USB device that is not ready yet. That is, you have the specification, you know its characteristics, but in fact, the device is not ready for you to do all the tests you need. In this case, the training kit would not help much. This is another point.

Joining these points, we can see that we are lost and the only way is just forget everything and go to sell coconut water at the beach.

A considerable alternative

Taking these same points, Microsoft has developed the Device Simulation Framework for USB Devices. This framework is composed of, among other components, a driver that is installed on your test machine that simulates an USB controller. This driver is Lower Filter Drivers for Windows USB controller drivers. It intercepts the interactions that Windows does with the actual hardware and simulate hardware interrupts. From driver’s viewpoint, there is no difference between DSF and real devices.

But how can the framework simulate a USB device that it doesn’t know? Actually, the framework redirects these interactions to components in User-Mode that can be written by you in any language that can use COM. This way, you can control device behavior being simulated. Observe the figure borrowed from the MSDN page, so you can have a clearer picture of how these components are organized.

Installing DSF

The DSF comes in the WDK ISO that you can download from Microsoft. It can only be installed on Windows XP SP2 or higher (including x64 platforms). When you install WDK on your machine, the DSF is not installed. You need to install it separately. The  dsfx86runtime.msi and dsfx64runtime.msi files, responsible for installation, are located in the \dsf of the ISO. The framework installation is extremely simple, but you can only see something when, after installed, you run “softehcicfg /install” command line at the “\Program Files\dsf\softehci” folder, as it is shown below.

This command creates a virtual USB controller in your device tree, which can be seen on Device Manager. Your system may ask the drivers for this new hardware that was added. If it does, enter the system directory (C:\Windows) for the search for drivers taking place. After the drivers have been installed, you should get two new devices. They are: Microsoft USB 2.0 EHCI Host Controller Simulator and USB Root Hub, as it is shown below.

Using VBScript to write devices

To simulate devices, DSF installs a group of components that implement COM objects, such as: Devices, Configurations, Interfaces, Endpoints, Descriptors, and so on. Who has already developed firmware for USB knows exactly what I mean. With these objects, you can write components that can simulate any USB device. Along the framework, three examples of devices that can be simulated are also installed. These devices’ sources are examples that come together in the WDK. They are located at \WinDDK6000\src\Test\DSF\USB. To use one of these examples, we just need a language script, or any language able to use COM interfaces.

Let’s take a look at the keyboard example and look for its IRPs. To make the keyboard work, go to the “\Program Files\dsf\usbhid” and run the following command line:  “cscript Create1.1Kbd.wsf” and follow the steps. If this is the first time you are doing this, Windows may ask the drivers for new devices that will be created. The script will create a Generic USB Hub and a USB Microsoft Natural Keyboard, as it is shown below.

Before removing these devices, let’s take a look using IRP Tracker, a software that I have mentioned in another post, and watch this simulated keyboard’s IRPs. Start the IRP Tracker and select all KbdClass driver. KbdClass is the driver responsible for centralizing and implementing interfaces for the keyboard device class. The IRPs from all keyboards are here.

While the first command prompt is stopped, start another one and from the same directory, run the following command line: “cscript Use1.1Kbd.wsf”. This script simulates pressing keys on the simulated keyboard writing the phrase “Hello World!”. For each key the system gets, records are generated from monitored IRPs. Thus, the IRP Tracker should look as it is shown below.

This is an excellent tool for using with virtual machines and it can anticipate a good amount of testing until the actual hardware is ready. In cases where the hardware and the driver are new, this could be a good way to discover which one is causing the issue. After all, hardware has bugs, too. Even if you’re a student and have no hardware, this could be useful to train your learning. At least, you will not burn anything.

See you!
